Matrix permanent magnet plate is a kind of new product of magnetic chuck for milling and CNC, Adopt brand new magnetic workholding technologies. The testing proves it apply to CNC, milling machine and facing machine, It is suitable for processing of high precision workpiece, sheet workpiece and mould.
Matrix magnet chuck meets the requirements of the high clmaping precision and short adjustment time in CNC and milling machine. The chucks can improve efficiency observably. Constant、even and foreseeable magnetic holding force. Available to change it simply and quickly, bring about 5 sides machining. The workpiece is allowed to exceed the area of working table, generally, it can reduce the assistant time more than 70%-80%.
The super strong magnetic holding force is from the combination of square or strip magnetic units. The units distributes intensively, powerful strength of magnetic fields. The magnetic plate can release the internal stress of workpiece in machining, get the high precision product of milling.
Product Features
1 Increase efficiency remarkably, constant, even and foreseeable magnetism, allow to change workpiece easily and swiftly.
2 Waterproofness of permanent magnet plate is excellent, allow to be used with cutting fluid.
3 Matrix permanent magnet chuck is made of NdFeB magnets.
